The Anker SOLIX X1 Hybrid Three-Phase is the hybrid inverter at the heart of an Anker SOLIX X1 home energy system for three-phase homes, and we install the 10 kW size. It runs your solar panels and the X1 battery modules from one unit.
When the grid drops, it switches to backup in under 10 milliseconds. It is IP66 rated, quiet, and mounts on the ground or the wall.
Key Features
- 10 kW, Three Phase: 10 kW rated output, 10 kVA maximum, 230/400 V three phase.
- Solar Input: up to 20 kW of solar panels on 2 MPPTs, 1,000 V maximum input.
- Battery Ready: up to six Anker SOLIX X1 battery modules, 30 kWh, a system.
- Fast Backup: on-grid to off-grid in under 10 ms, with 20 kVA peak output for 10 seconds.
- IP66 Rated: for indoor or outdoor installation.
- Quiet: 30 dB or less.
- Size: 670 x 450 x 150 mm; ground or wall mounted.
- 10-Year Warranty.
